• Heating to 180℃,about 15~20 mins;180℃ cooling down to 60℃ about 3~5mins (accords to different size press), temperature error(on 650mm Up and bottom hot plate )is less than 3℃.
Reliable and automatic Temperature Control Panel with time control.
• Water cooling pump
Long life time and fast splicing.
If the press is required for workshop use,
Opening system & steel housing is Optional.
• Voltage: 220V or 380V, if special voltage freely inform us.
Standard width: 1m, 1.6m,2m ect. We can prodce as requirement.
| Model |
UW600 |
UW900 |
UW1000 |
UW1200 |
UW1600 |
UW2000 |
| Effective Length (mm) |
600 |
900 |
1000 |
1200 |
1600 |
2000 |
| Effective Width (mm) |
150 |
150 |
150 |
150 |
150 |
150 |
| Weight upper Part (KG) |
18 |
30 |
35 |
35 |
57 |
94 |
| Weight Lower Part (KG) |
20 |
30 |
41 |
41 |
63 |
102 |
| Total Weight (KG) |
45 |
65 |
87 |
87 |
125 |
196 |
| Overall Length (mm) |
720 |
1020 |
1410 |
1410 |
1910 |
2420 |
| Overall Height (mm) |
310 |
310 |
310 |
310 |
390 |
390 |
| Max Pressure (Bar) |
2 |
2 |
2 |
2 |
2 |
2 |
| Max Temperature (℃) |
200 |
200 |
200 |
200 |
200 |
200 |
| Packaging List(L*W*H) (mm) |
1460*500*540 |
1670*520*540 |
2050*480*540 |
2060*480*540 |
2450*550*490 |
2950*600*490 |
| Packing Weight (KG) |
72 |
90 |
135 |
145 |
200 |
264 |
| Power(W) |
2016 |
3024 |
3696 |
3300 |
5760 |
7560 |
